Mikuni TMX38 Flat Slide 38mm Carburetor - 47mm

The TMX features a flat slide design in a smooth bore venturi to provide improved throttle response and wider power-band. The float system, with independently moving floats, works with a main-jet, enclosed in a baffle chamber. This allows smooth performance on the roughest terrain.

TM Series Carburetors provide significant performance improvements over older design round slide carburetors. Air flows faster and smoother through the TM Series venturi due to the flat slide configuration and the jet blocks which help create a smooth-bore effect. The high velocity of the air flow means a stronger vacuum at the needle jet, providing more precise metering and better throttle response.

This TMX38-18Typically used on high performance 250cc Two Stroke engines while the TMX35-1 is used for 125cc race bikes.

Dimensions:

• Outside dimension at engine manifold spigot: 47mm
• Outside dimension at intake bell: 62mm
• Overall length (end of spigot to end of intake bell): 76mm
• Overall height 164mm
• Total width 76m
