Name: Mikuni VM40 Exploded View - Replacement Parts Listing
SKU: VM40_parts_list

VM40 Parts List

Our Mikuni parts finder may assist you in finding the replacement parts you need.  The list of parts shown is specific to the carburetor listed, and should not be assumed to fit similar models, especially older carburetors, and Mikuni carburetors that came as an OE part.  Any product listed that is available in different sizes will allow a selection to be made on parent item page.  If you are unsure of your selection, please contact us for assistance.

No.	Sku	Name	Price	Qty
1	VM26/46	Mikuni Cable Adjuster Rubber Cap More Info >	$3.85
2	M21/14	Mikuni VM Series Cable Adjuster - 6mm More Info >	$3.70
3	B30/247	Mikuni Cable Adjuster Locknut More Info >	$2.00
4	VM44/05	Mikuni VM40/44 Carburetor Cap More Info >	$23.70
5	VM36/06	Mikuni Carburetor Top Cover Gasket - Packing More Info >	$3.90
6	VM44/13	Mikuni VM40-VM44 Throttle Spring More Info >	$17.50
7	VM44/09	Mikuni VM40-VM44 Throttle Spring Seat Plate More Info >	$5.50
8	BS32/126	Mikuni Jet Needle Positioning E-Ring Clip More Info >	$2.15
10	VM40/02	Mikuni VM40/02 - Throttle Slides More Info >	Starting at $42.95
11	VM44/224	Mikuni 224 Series Needle Jets More Info >	Starting at $15.95
12	VM20/455	Mikuni Choke Rubber Cap More Info >	$3.20
13	VM20/456	Mikuni VM30-VM44 Starter Plunger Fitting Cap More Info >	$5.10
14	VM36/58	Mikuni VM22 Flange VM40-44 Spigot Choke Lever Assembly More Info >	$16.60
15	VM32/17	Mikuni Choke Plunger Spring Plate More Info >	$3.50
16	VM16/42	Mikuni Choke Plunger Spring More Info >	$3.80
17	VM18/144	Mikuni Starter, Choke Plunger Fitting - VM26-44 Flange Type More Info >	$7.00
20	VM44/12	Mikuni Baffle Plate	$14.95	Out of stock
21	VM22/210	Mikuni VM22/210 Pilot Jets More Info >	Starting at $4.65
22	VM30/160	Mikuni Float Arm Hinge Pin - With Head More Info >	$3.35
23	VM36/15	Mikuni TM Series Float Arm More Info >	$9.75
24	VM24/236	Mikuni VM26-VM30 VM36-VM44 Flange TM32 TM36 TM38 Independent Float More Info >	$14.15
25	VM44/04-80	Mikuni VM40 VM44 Float Bowl More Info >	$56.95
26	VM28/134	Mikuni Float Bowl Drain Plug Washer More Info >	$3.20
27	VM28/133	Mikuni Float Bowl Plug - VM26-8074, VM40-VM44 More Info >	$13.30
28	BS30/97	Mikuni BS30/97 Air Jets More Info >	Starting at $4.65
29	VM20/214	Mikuni Air Adjustment Scew More Info >	$6.00
31	M20/11	Mikuni Idle Adjuster Screw Spring More Info >	$2.60
32	VM24/224	Mikuni Idle Adjuster Screw More Info >	$7.80
33	B34/52-0.8	Needle Valve Seat Washer - 0.8	$1.35
34	VM34/39	Mikuni VM34/39 - Metal Tip Needle & Seat Assembly More Info >	Starting at $26.10
35	VM28/228	Mikuni Brass Main Jet Ring VM26-VM28, VM40-VM44 More Info >	$12.25
36	VM4/042	Mikuni VM4/042 Large Hex Main Jets More Info >	Starting at $4.65
37	VM28/79	Vent Line Retaining Plate More Info >	$4.55
38	CW2-0518	Mikuni Float Bowl Screw (5x18mm) More Info >	$1.70
