XV535-1100 Virago 1981-2003

This Yamaha Virago Manual is 520 pages.

Section One: XV700-1100 Virago 1981-1999
Section Two: XV535 Virago 1987-2003

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Service hints / Torque speecifications / Safety first / Special tips / Expendable supplies / Parts replacement / Serial numbers / Basic hand tools/ Tune-up and troubleshooting tools / Mechanic's Tips

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Troubleshooting instruments / Emergency troubleshootng / Engine starting / Engine performance / Engine noises / Excessive vibration / Clutch / Transmission / Front suspension and steering / Brake problems / Electrical problems / Ignition system

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Routine checks / Maintenance schedule intervals / Tires and wheels / Battery / Lubrication / Engine oil and filter change / Oil pressure check / Final drive oil check and change / Fork oil change / Speedometer cable lubrication / Maintenance / Drive chain adjustment / Brake adjustment and inspection / Clutch adjustment / Throttle adjustment / Air cleaner service / Drive chain / Tune-up / Valve clearance adjustment / Compression test / Spark plug / Ignition timing / Carburetor idle mixture / Carburetor synchronization / Carburetor idle speed adjustment / Specifications

CHAPTER FOUR / ENGINE
Removal installation / Heads and camshafts / Valves and components / Rocker arm / Cylinder / Pistons and rings / Oil pump strainer / Oil pressure relief valve / Oil level switch / Neutral switch / Timing gears / Primary drive gear / Crankcase / Crankshaft and connecting rods / Middle drive gear / Starter gears / Break-in / Specifications

CHAPTER FIVE / CLUTCH AND TRANSMISSION
Clutch / Clutch cable / Drive sprocket / Shift mechanism / Transmission / Shift drum and forks / Specifications

CHAPTER SIX / FUEL AND EXHAUST SYSTEMS
Air cleaner / Carburetors / Coasting enrichener system / Fuel level measurement / Choke cable / Rejetting carburetors / Throttle cable / Choke cable / Shutoff valve / Filter / Fuel pump / Tank / Crankcase breather system / Mixture control valve / Air induction system / Exhaust / Specifications

CHAPTER SEVEN / ELECTRICAL SYSTEM
Charging system / Alternator / Voltage regulator rectifier / Ignition system / Igniter unit / Ignition coil / Pickup coil / Spark plugs / Pressure sensor / Starting system / Electrical components / Lighting system / Switches / Computerized monitor system / Fuel pump testing / Fuel warning light system / Horn / Fuses / Specifications

CHAPTER EIGHT / FRONT SUSPENSION AND STEERING
Wheel and hub / Tires / Handlebar / Steering head / Front fork / Specifications

CHAPTER NINE / REAR SUSPENSION AND FINAL DRIVE
Wheel and hub / Clutch hub / Drive chain assembly / Final shaft drive / Swing arm / Shock absorbers / Specifications

CHAPTER TEN / BRAKES
Front disc brake / Master cylinder / Front brake pad replacement / Front caliper / Front brake hose replacement / Front brake disc / Rear drum brake / Rear brake pedal assembly / Bleeding the system

CHAPTER ELEVEN / SUSPENSION ADJUSTMENT
Front fork / Rear shock absorbers / Specifications

INDEX

WIRING DIAGRAMS

Models covered:
1984 1985 Yamaha XV1000 XV 1000
1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 Yamaha XV1100 XV 1100
1987 1988 1989 1990, 1993 1994 1995 1996 1997 1998 1999 2000 Yamaha XV535 XV 535
1988 1989 1990 1991 1992 1993 1994 19995 1996 1997 1998 1999 2000 2001 2002 2003 Yamaha XV535 (U.K.) XV 535
1984 1985 1986 1987 Yamaha XV700 XV 700
1981-1983 & 1988-1997 Yamaha XV750 XV 750
1981-1983,1988-1997 Yamaha XV750 XV 750
1982-1983 Yamaha XV920 XV 920


Clymer Yamaha Virago XV535 Manual
Clymer Yamaha Virago XV700 Manual
Clymer Yamaha Virago XV750 Manual
Clymer Yamaha Virago XV920 Manual
Clymer Yamaha Virago XV1000 Manual
Clymer Yamaha Virago XV1100 Manual


XV535 (U.S. 1987-1990, 1993-2000) (U.K. 1988-2003)
XV700 (1984-1987)
XV750 (1981-1983, 1988-1997
XV920 (1982-1983)
XV1000 (1984-1985)
XV1100 (1986-1999)
